1. Profile

Common European style upvc profile, American style vinyl profile

2. Profile thickness

2.0 mm-3.0mm, customized, galvanized steel reinforcement: 1.0-2.0mm

3. Color

White, Brown, Green, Grey, full body color profile, ASA co-extrusion color, laminated with wood film

4. Window Glass option

Option: Clear, tinted, Low-E, tempered, insulated, reflective, frosted, fireproof, laminated, fireproof, smart glass,etc.

Thickness:4,5,6,8mm, 5mm-9A-5mm, 6mm-9A-6mm, triple glazing.

5. Hardware

USA brand: Truth, Active, German, Australia brand, China top brand

6. Seal & strip

Rubber sealing strip, black or grey color

7.Window screen& Louver

Nylon/fiberglass mesh material, blind shutter, jalousie, ventilation grill available

8. Applications

Office, apartment, villa, basement, garden, hotel, hospital, residential housing.

1. The wall thickness of the main profile meets the requirements of the China standard GB/T8814-2004 for profiles and the standard GB/T28887-2012 for plastic windows for construction;

2. Standard notch design, which improves the performance of the whole window, realizes flexible opening, convenient use and security anti-theft function;

3. The large section design of the profile, the internal fan material adopts the integrated design, and the principle of equal pressure and decompression between the outer frame and the inner fan improves the airtightness of the door and window and the torque resistance of the profile itself, the drop hammer impact, etc. Ensure that doors and windows are not easy to crack in cold regions;

4. Reasonable drainage channel design to effectively prevent rainwater from penetrating;

5. The four corners of the sash are made of stainless steel corner reinforcement, and the 45 degree angle is more precise;

6. The frame is a double-track structure, and the frame and fan have unique drainage groove design;
